- CLAMPTEK TOGGLE CLAMPS
 TOGGLE CLAMPS VERTICAL & HORIZONTAL  PUSH / PULL TYPE TOGGLE CLAMPS  LATCH TYPE TOGGLE CLAMPS  PNEUMATIC POWERED TOGGLE CLAMPS |
|---|
- VERTICAL HANDLE TOGGLE CLAMPS
| FLANGED BASE TYPE WITH STRAIGHT HANDLE | |||||||
| PART # | HOLDING CAP. | SPINDLE TYPE | REACH | WEIGHT | |||
| CH-10752-B | 75KG | BOLT | 31mm | 50g |  |
||
| CH-12050 | 91KG | CUSHION | 32.9mm | 170g |  |
||
| CH-11502-B | 150KG | BOLT | 43mm | 230g | |
||
| CH-101-D-15 | 180KG | CUSHION | 154mm | 412g |  |
||
| CH-101-E-20 | 180KG | CUSHION | 204mm | 440g |  |
||
| CH-12205 | 182KG | CUSHION | 106.3mm | 620g |  |
||
| CH-11421 | 200KG | BOLT | 63mm | 370g |  |
||
| CH-12132 | 227KG | CUSHION | 95.2mm | 370g |  |
||
| CH-12265 | 340KG | CUSHION | 85.1mm | 635g |  |
||
| CH-101-EL | 360KG | CUSHION | 85mm | 860g |  |
||
| CH-101-H | 450KG | BOLT | 128mm | 1250g |  |
||
| CH-10247 | 450KG | BOLT | 125.4mm | 1250g |  |
||
| FLANGED BASE TYPE WITH TEE HANDLE | |||||||
| PART # | HOLDING CAP. | SPINDLE TYPE | REACH | WEIGHT | |||
| CH-12133 | 227KG | CUSHION | 95.2mm | 400g |  |
||
| CH-12285 | 340KG | CUSHION | 85.1mm | 710g |  |
||
| STRAIGHT BASE TYPE WITH STRAIGHT HANDLE | |||||||
| PART # | HOLDING CAP. | SPINDLE TYPE | REACH | WEIGHT | |||
| CH-10751-B | 75KG | BOLT | 31mm | 50g |  |
||
| CH-11501-B | 150KG | BOLT | 43mm | 230g |  |
||
| CH-12210 | 182KG | CUSHION | 106.3mm | 620g |  |
||
| CH-12137 | 227KG | CUSHION | 95.2mm | 370g |  |
||
| CH-12270 | 340KG | CUSHION | 85.1mm | 635g |  |
||
| CH-10248 | 450KG | BOLT | 125.4mm | 1250g |  |
||
- HORIZONTAL HANDLE TOGGLE CLAMPS
| FLANGED BASE TYPE | |||||||
| PART # | HOLDING CAP. | SPINDLE TYPE | REACH | WEIGHT | |||
| CH-201-B | 90KG | CUSHION | 56.2mm | 130g |  |
||
| CH-225-D | 227KG | CUSHION | 70mm | 265g |  |
||
| CH-22165 | 250KG | CUSHION | 71.4mm | 285g |  |
||
| CH-20235 | 340KG | CUSHION | 107mm | 700g |  |
||
| STRAIGHT BASE TYPE | |||||||
| PART # | HOLDING CAP. | SPINDLE TYPE | REACH | WEIGHT | |||
| CH-201-BI | 90KG | CUSHION | 56.2mm | 130g |  |
||
| CH-225-DI | 227KG | CUSHION | 70mm | 265g |  |
||
| CH-22170 | 250KG | CUSHION | 71.4mm | 285g |  |
||
| CH-20236 | 340KG | CUSHION | 107mm | 700g |  |
||
| SIDE MOUNT TYPE | |||||||
| PART # | HOLDING CAP. | SPINDLE TYPE | REACH | WEIGHT | |||
| CH-225-DSM | 227KG | CUSHION | 67 | 315g |  |
||
- PUSH / PULL TYPE TOGGLE CLAMPS
- LATCH TYPE TOGGLE CLAMPS
| STRAIGHT TYPE | |||||||
| PART # | HOLDING CAP. | U BOLT LENGTH | U BOLT WIDTH | WEIGHT | |||
| CH-40323 | 163KG | 57mm | 28.2mm | 70g |  |
||
| CH-431 | 318KG | 87mm | 44.4mm | 225g |  |
||
| CH-40341 | 900KG | 115mm | 54mm | 680g |  |
||
| CORNER TYPE | |||||||
| PART # | HOLDING CAP. | U BOLT LENGTH | U BOLT WIDTH | WEIGHT | |||
| CH-40324 | 225KG | 78.5mm | 22mm | 100g |  |
||
| CH-40334 | 450KG | 114mm | 25.4mm | 290g |  |
||
| CH-40344 | 900KG | 154mm | 36.5mm | 660g |  |
||
- PNEUMATIC POWERED TOGGLE CLAMPS
| PART # | SPINDLE TYPE | REACH | WEIGHT | |||
| CH-12050-UA | CUSHION | 35mm | 620g |  |
||
| CH-12130-A | CUSHION | 68mm | 900g |  |
||
| CH-12132-A | CUSHION | 88mm | 900g |  |
||
| CH-12265-A | CUSHION | 92mm | 1640g |  |
||
| CH-10247-A | BOLT | 125.4mm | 3620g |  |
